Products center

Pneumatic Riveting Machine

Pneumatic Riveting Machine

  • Product classification：Pneumatic riveting machine

    Core Functions
    Radial riveting, swing riveting, press riveting, spin riveting
    Suitable Industries
    Hardware fittings, electronic components, automotive parts, medical devices
    Key Structure and Configuration
    ●  Chassis: C-frame cast steel / aluminum alloy structure, high rigidity
    ● Drive System: Pneumatic cylinder / hydraulic cylinder / servo motor
    ● Riveting Head System: Carbide riveting heads, wear-resistant and durable
    ● Control System: Manual buttons / foot switch; some models feature CNC

  • Detail

產品型號與核心參數

型號

公稱壓力

鉚接范圍

行程

功率

類型

ZHUEN-136-Q2

2 T

φ1–φ5 mm

50 mm

0.1 KW

氣壓

ZHUEN-137-Y5

5 T

φ3–φ10 mm

100 mm

2.2 KW

油壓

ZHUEN-138-S10

10 T

φ5–φ15 mm

150 mm

5.5 KW

伺服



性能特點與優勢
● 伺服款實現壓力 - 位移雙控，鉚接精度 ±0.01mm
● 氣壓款速度快，適合小批量生產
● 油壓款壓力穩定，適合大噸位鉚接
● 鉚頭快速更換，適配多規格鉚釘

安全與合規標準
標配急停按鈕、雙手啟動、安全防護網

定制與服務信息
● 支持鉚接范圍、鉚頭、行程定制
● 提供免費安裝調試、操作培訓、12 個月質保
● 可加裝自動送釘裝置，提高生產效率
